SPM/FMC Type Plug Valve Repair Kit Fig 1502 Interchangeability
Parts code:4L11769 and 4L11982,etc
KUOFU have 1" 2" and 3" size Plug valve repair kits,can be provided for standard service, or low temperature and sour gas condition. These repair kits are replaceable and interchangeable for Weir SPM™, FMC™ plug Valve repair kits, which is including plug, seal segment, side segment, elastomer seals, and grease fittings
| Name | 1"×2"plug valve | 2"×2"plug valve | 3"×3"plug valve | ||||||
| Qty. | 105Mpa | 70Mpa | 42Mpa | 105Mpa | 70Mpa | 42Mpa | 105Mpa | 70Mpa | 42Mpa |
| 15000psi | 10000psi | 6000psi | 15000psi | 10000psi | 6000psi | 15000psi | 10000psi | 6000psi | |
| Side segment | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Seal segment | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Inner seal and Outer seal | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Plug | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Lock nut, Hex | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| O-ring for body cap | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| O-ring for plug | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Nylon backup ring | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Grease Retainer Ring | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Grease fitting | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
